SPECIFICATIONS
Product Dimension | 676mm*2050mm*713mm/2.22’*6.73’*2.34′ |
Product Weight | 230kg/506lbs |
Product Material | Q345 Steel |
Hydraulic Motor Flow | 50L per min |
Hydraulic Motor Pressure | 20MPa |
Surface Treatment Technology | Plastic Powder Coating |
Working Width | 1830mm/72.05″ |
Working Depth | 160mm/6.3″ |
Working Rotation Speed | 160 RPM |
Number Of Tine | 4*9 group |
Tine Material | 65Mn Steel |
Package Size | Package Weight |
2.2m*0.7m*0.7m/86.61″*27.56″*27.56″ | 280kg/616lbs |
