• Specifications:

Engine: Briggs and Stratton (B&S)

• 10KW (23HP) engine power
• Rotating Speed: 3600 rpm
• Noise (Db): <95

Hydraulic System:

• Pressure (Mpa): 17
• Working Time (s):
  • Raise: 4 seconds
  • Dump: 1.3 seconds
  • Lower: 3.2 seconds

Key Features:

• Operational Load: 573.2 lbs
• Bucket Capacity: 3 cubic feet
• Max Lifting Force: 661.39 lbs
• Travel Speed: 3.73 miles per hour
• Operating Weight: 1410 lbs

Dimensions and Performance:

• Max Working Height (H3): 98.58 inches
• Max Pin Height (H2): 76.81 inches
• Max Dumping Height (H1): 56.02 inches
• Max Dumping Distance (E): 3.94 inches
• Max Dumping Angle (a3): 53°
• Rollback of Bucket on Ground (a2): 32°
• Departure Angle (a1): 17°
• Total Height (H): 47.64 inches
• Ground Clearance (F): 5.26 inches
• Wheel Base (L1): 25.71 inches
• Overall Length without Bucket (L3): 61.1 inches
• Total Width (B2): 41.34 inches
• Bucket Width (B1): 42.52 inches
• Total Length with Bucket (L): 78.43 inches
• Turn Radius Forward Turning (R): 47.44 inches
