The CAEL Compact Hydraulic Excavator is engineered for superior performance, precision, and reliability. Designed for construction, landscaping, and utility applications, this machine features advanced hydraulics, a fuel-efficient Yanmar engine, and a robust undercarriage. With EPA Tier 4 compliance and powerful digging capabilities, it delivers exceptional productivity in confined and demanding work environments.
Engine Specifications
| Parameter | Specification |
|---|---|
| Brand | CAEL |
| Engine | Yanmar |
| Engine Make/Model | Kubota D1703 |
| Emission Standard | EPA Tier 4 |
| Rated Power | 18.5 kW (25 HP) @ 2200 rpm |
| Maximum Torque | 97.4 N·m @ 1500 rpm |
| Number of Cylinders | 3 |
| Engine Type | In-line, Water-Cooled, 4-Stroke, Naturally Aspirated |
| Fuel System | Mechanical Pump |
| Displacement | 1.647 L |
Track Driving System
| Parameter | Specification |
|---|---|
| Maximum Travel Speed (High/Low) | 4.4 / 2.4 km/h |
| Width of Steel Track Shoe | 300 mm (11.81 in) |
| Carrier Rollers (Each Side) | 1 |
| Supporting Rollers (Each Side) | 4 |
Performance Parameters
| Parameter | Specification |
|---|---|
| Standard Bucket Capacity | 0.12 m³ |
| Swing Speed | 9 rpm |
| Maximum Gradeability | 58% |
| Ground Pressure | 32 kPa |
| Maximum Bucket Digging Force | 30.4 kN |
| Maximum Arm Digging Force | 18.2 kN |
| Hydraulic System Pressure | 22.5 MPa |
| Machine Weight | 3,810 kg (8,399.6 lbs) |
| Boom Length | 2,535 mm (99.80 in) |
| Arm Length | 1,400 mm (55.11 in) |
Fluid Capacities
| Parameter | Specification |
|---|---|
| Fuel Tank Capacity | 42 L |
| Hydraulic Tank Capacity | 48.5 L |
| Engine Oil Capacity | 7 L |
Machine Dimensions
| Parameter | Specification |
|---|---|
| Overall Dimensions (L × W × H) | 4,915 × 1,720 × 2,525 mm (193.5 × 67.7 × 99.4 in) |
| Track Length on Ground (Wheelbase) | 1,670 mm (65.74 in) |
| Length of Rubber Track | 2,154 mm (84.80 in) |
| Track Gauge | 1,420 mm (55.90 in) |
| Minimum Ground Clearance | 295 mm (11.61 in) |
| Rear Swing Radius | 860 mm (33.85 in) |
| Front Swing Radius | 2,538 mm (99.60 in) |
| Blade Height | 350 mm (13.77 in) |
Working Range
| Parameter | Specification |
|---|---|
| Maximum Digging Height | 4,800 mm (188.97 in) |
| Maximum Dumping Height | 3,406 mm (134.09 in) |
| Maximum Digging Depth | 3,208 mm (126.29 in) |
| Maximum Vertical Digging Depth | 2,957 mm (116.41 in) |
| Maximum Digging Reach | 5,480 mm (215.74 in) |
| Maximum Ground-Level Reach | 5,395 mm (212.40 in) |
| Minimum Swing Radius | 2,530 mm (99.60 in) |
| Maximum Height at Minimum Swing Radius | 2,530 mm (99.60 in) |
| Maximum Blade Lift Height | 365 mm (14.37 in) |
| Maximum Blade Cutting Depth | 385 mm (15.15 in) |
| Boom Swing Angle (Left/Right) | 55° / 65° |
Warranty
- 2-Year Warranty on Motor
- 1-Year Warranty on All Parts
Optional Attachment
| Attachment | Price |
|---|---|
| Hydraulic Thumb | C$2,500 |
Key Features
- ✔ Reliable and fuel-efficient Yanmar engine
- ✔ EPA Tier 4 compliant for reduced emissions
- ✔ Powerful digging performance and high hydraulic efficiency
- ✔ Compact design ideal for confined job sites
- ✔ Durable undercarriage for enhanced stability
- ✔ Smooth and precise control system
- ✔ Advanced cooling and lubrication systems
- ✔ Low maintenance and operational costs
