Description
Key Specifications:
Lifting Capacity: 3500 Kg/ 7800 LBS
Lifting Height: 1850mm/ 73 in
Lifting time: 50 sec
Platform length with no ramp : 1480mm/58.2in
Platform length with ramp: 2090mm/82.2in
Platform width: 690 mm/ 27.1 in
Motor power: 2.2 kW
Voltage: 110V
Rated oil pressure: 20 Mpa
