CAEL 23 FT Telescopic handler forklift truck

BRAND NEW CAEL telehandler 4×4 All Terrain with Diesel Cummins Engine 23 FT  was designed to be operated on narrow spaces, slippery ground and can handle with heavy workloads.
Its compact dimensions, incredible maneuverability, unparalleled build quality and all-day operator comfort are just the ideal
machine you are looking for.
As a purpose-built machine to the exact needs of agricultural operators. You can therefore also expect maximum productivity, efficiency , safety and serviceability

Models:

– Telehandler ( 23FT ) : 3.5ton loading, Cummins EPA Tier-4 engine 55kw, Luxury cabin with Aircon, 4 wheel steering,1220mm floating fork, Overloading warning system

Model CAEL 23-TH

Engine Cummins

Rated power 76.7kw

Type Four stroke, diesel engine

Displacement 3760L

Performance

Max. lifting capacity 3500kg

Max. lifting capacity at max. Reach 2800kg

Capacity at max. boom extension | 1100kg

Max. lifting height 7000mm

Max. horizontal boom extension 3300mm

Gradeablity 30%

Machine weight 8500kg

Max. speed 40km/h

Differential Axles

Driving model 4WS, Crab steering, 2WS

Front axle Rigid

Rear axle Oscillating

Moving brake Servise air brake(disc) on the 4 wheels

with double hydraulic system

Parking brake Negative parking brake

Tires 405/70-20

Dimensions

Length (without fork) D 5300mm

Height F 2300mm

Width H 2150mm

Shaft distance B1 2950mm

Tire distance G 1760mm

Cabin width E 910mm

Ground clearance A 370mm

Front tires to Rear chassis C 4050mm

Standard fork length

Option

Overloading warming &  Limitation

Titable chassis(+-6)

Sideshift

Fork positioner

Raisable cabin

Big bucket for bulk cargo

Normal bucket for construction

Working platform( fordable— a working platform, swing working

= G platform etc…)

attachments(Hook.grapple auger

Mixing bucket.tilted fork.4in1

bucket, winch, baler, manipulator)
