Engineered for powerful winter performance, the CAEL Skid Steer Snow Blower is built to handle heavy snow with ease. Designed for durability and efficiency, it delivers strong throwing distance, high-capacity clearing, and reliable operation—making it ideal for commercial and industrial use.

Key Features

High-Performance Snow Clearing
Efficiently removes large volumes of snow with a powerful auger and blower system, reducing clearing time.

Long Throwing Distance
Capable of throwing snow up to 15 m (49.21 ft), ensuring effective snow displacement away from work areas.

Heavy-Duty Q345 Steel Construction
Built from high-strength steel for maximum durability and long-term performance in harsh winter conditions.

Powerful Hydraulic System
Supports hydraulic motor power from 15 HP to 45 HP, delivering strong and consistent performance.

Wide Working Coverage
Provides a working width of approximately 1600 mm (62.99 in / ~63″) for efficient snow clearing.

Corrosion-Resistant Finish
Plastic powder coating protects against rust, wear, and extreme weather.

Product Specifications

Working Width:
1600 mm (62.99 in / ~63″)
Nominal width: 68″

Blowing Distance:
≥ 12,000 mm (12 m)
Up to 15 m (49.21 ft)

Operating Pressure:
17 – 21 MPa

Hydraulic Motor Pressure:
20 MPa

Operating Flow:
100 – 125 L/min

Hydraulic Motor Power:
15 HP – 45 HP

Working Rotation Speed:
560 – 1680 RPM

Dimensions & Build

Product Dimensions:
1800 mm × 1170 mm × 1540 mm
(5.91 ft × 3.84 ft × 5.05 ft)

Product Weight:
520 kg (1,144 lb)

Material:
Q345 High-Strength Steel

Surface Treatment:
Plastic Powder Coating

Component Details

Blower Diameter:
615 mm (24.21 in)

Auger Diameter:
465 mm (18.31 in)

Clearing Height:
465 mm (18.31 in)
