Description
Unleash the power of the CAELMS1235 Mobile Screener with Yanmar Engine for your construction site, quarry, or demolition project. These screeners are engineered to handle all types of daily tasks, operating smoothly and quietly with a host of advanced features. Fully integrated systems guarantee outstanding performance for both primary and secondary screening needs.
Prices:
- Contact us for the latest pricing and offers.
Description:
Hopper / Feeder
-
Stock Bin Volume: 1.5m³
-
Belt Feeder: B800*4500mm
Vibrating Screener
-
Model: 2YK1200*3600
-
Number of Screen Layers: 2
-
Mesh Size (mm): 5/40 (Custom made)
-
Maximum Feed Particle Size: 200mm
-
Throughput: 30-80t/h
Belt Conveyor
-
Side Conveyor: B500*5000
-
Under Screen Conveyor: B800*6000
Driving System
-
Engine: Stage IIIA/V: 36kW (48HP)
Basic Parameters
-
Weight: 8500kg
-
Working Size (LxWxH): 890075203200mm
-
Transportation Size (LxWxH): 810022502650mm
[Key Features]
- High-efficiency screening for various materials.
- Two-deck, three-way screening for versatile applications.
- Compact design for easy transport and rapid setup.
- Low maintenance and high durability.
- Fuel-efficient and powerful Yanmar engine with warranty.
- One-year warranty for parts only.
The CAELMS1235
The CAELMS1235 is a two-deck, three-way mobile screener, ideal for small to medium-sized operators and contractors. This versatile product is capable of handling a range of applications, including sand and gravel, aggregates, and recycling. The CAELMS1235 can be set up rapidly and transported easily, making it an excellent solution for various applications with a capacity of up to 50-100 tph.
