The CAEL Plate Compactor GCR360 is a powerful, contractor-grade compactor designed for deep soil compaction and large-scale construction projects. Built with a durable cast iron base and high-impact vibration system, it delivers superior performance on dense soils, aggregates, and heavy groundwork.

Powered by the reliable Briggs & Stratton 19N1 engine, the GCR360 ensures consistent power, durability, and efficient operation even under demanding conditions.

Key Features

• Centrifugal Force: 30 kN for maximum compaction power
• Compaction Depth: 450 mm (17.7 inches) for deep soil stability
• Plate Size: 700 × 500 mm (27.56 × 19.69 inches) cast iron base
• Frequency: 70 Hz for heavy-duty applications
• Travel Speed: 18 cm/s (7.09 in/s) for controlled operation
• Engine Output: 9.0 HP
• Operating Weight: 170 kg (375 lbs) for stronger ground impact

Specifications

• Model: CAEL GCR360
• Plate Material: Cast Iron
• Plate Size: 700 × 500 mm (27.56 × 19.69 inches)
• Frequency: 70 Hz
• Centrifugal Force: 30 kN
• Compaction Depth: 450 mm (17.7 inches)
• Travel Speed: 18 cm/s (7.09 in/s)
• Engine: Briggs & Stratton (Manual Start, CE/ISO Certified)
• Weight: 170 kg (375 lbs)
• Packing Size: 890 × 580 × 1120 mm (35.0 × 22.8 × 44.1 inches)

Applications

Road construction • Industrial foundations • Backfill • Pavements • Infrastructure projects

The CAEL GCR360 delivers maximum power, deeper compaction, and rugged durability, making it the ideal choice for heavy-duty and large-area compaction work.
