CAEL Integrated Tow & Recovery System
Heavy-Duty Professional Wrecker Body | High-Performance Vehicle Recovery Solution
The CAEL Integrated Tow & Recovery System is a heavy-duty towing and recovery solution designed for commercial towing fleets, roadside assistance operators, municipalities, transport companies, and professional recovery businesses.
Featuring a powerful recovery boom, versatile underlift system, dual winches, and flexible chassis compatibility, this integrated system is engineered to handle demanding towing, lifting, and vehicle recovery operations.
Built for durability, operational efficiency, and professional performance, the CAEL Integrated Tow & Recovery System offers customizable configurations to meet a wide range of commercial recovery requirements.
Key Features
- Heavy-Duty Recovery Boom
- 24,000 lbs Retracted Boom Capacity
- 20,000 lbs Tow Rating
- Versatile Underlift System
- Dual 12,000 lbs Winches
- Extended and Retracted Towing Capability
- Professional-Grade Wrecker Body
- Medium & Heavy-Duty Chassis Compatibility
- Custom Configuration Options
- Commercial-Grade Recovery Performance
Technical Specifications
Boom Specifications
| Specification | Details |
|---|---|
| Retracted Capacity | 24,000 lbs |
| Extended Capacity | 10,000 lbs |
| Maximum Boom Angle | 40° |
| Maximum Hook Height | 147 in |
| Maximum Reach Past Tailboard | 72 in |
Underlift Specifications
| Specification | Details |
|---|---|
| Fully Retracted Capacity (with Forks) | 9,000 lbs |
| Fully Extended Capacity (with Forks) | 7,000 lbs |
| Capacity with L-Arms (Extended or Retracted) | 6,000 lbs |
| Ground Reach (Retracted) | 42 in |
| Ground Reach (Extended) | 76 in |
| Positive Tilt | 28° |
| Negative Tilt | 12° |
| Tow Rating | 20,000 lbs |
Winch Specifications
| Specification | Details |
|---|---|
| Winch Rating (Each) | 12,000 lbs |
| Number of Winches | 2 |
| Cable Diameter | 7/16 in |
| Cable Length | 150 ft |
| Cable Type | IWRC |
Recommended Chassis Specifications
| Specification | Details |
|---|---|
| Suggested GVWR | 21,000–31,000 lbs |
| Cab-to-Axle | 84 in or 108 in |
| Maximum Frame Height | 37 in |
| Maximum Tire Size | 255/70R22.5 |
| Chassis Compatibility | Medium & Heavy-Duty Commercial Truck Chassis |
Ideal Applications
- Commercial Towing Fleets
- Medium-Duty Vehicle Recovery
- Accident & Emergency Recovery
- Municipal Towing Services
- Fleet Transport Operations
- Roadside Assistance Businesses
- Equipment Relocation
- Commercial Vehicle Recovery
Customization & Configuration
The CAEL Integrated Tow & Recovery System offers customization options to accommodate different commercial towing requirements.
- Custom Chassis Compatibility
- Application-Specific Configurations
- Professional Recovery Equipment Options
- Tailored Builds for Commercial Fleets
Why Choose CAEL?
- Professional-Grade Towing Equipment
- Heavy-Duty Recovery Performance
- Durable Commercial Design
- Flexible Chassis Compatibility
- Custom Build Options
- Canada-Wide Delivery
- Dedicated Support for Commercial Applications
Core Advantages
| Feature | Capacity / Benefit |
|---|---|
| Boom Capacity (Retracted) | 24,000 lbs |
| Tow Rating | 20,000 lbs |
| Dual Winch Capacity | 12,000 lbs Each |
| Underlift Capacity (Retracted with Forks) | 9,000 lbs |
| Underlift Capacity (Extended with Forks) | 7,000 lbs |
| Chassis Compatibility | Multiple Configurations |
| Customization | Available |
Important Note
All listed capacities are based on structural and design ratings. Actual towing and recovery performance depends on the selected truck chassis, vehicle weight, equipment configuration, and operating conditions.
Higher chassis specifications may be required depending on the total truck weight and installed equipment. Proper chassis selection and configuration are essential for safe and efficient operation.
Request a Quote
Looking for a reliable heavy-duty towing and recovery solution for your business?
Contact CAEL today for pricing, custom configurations, stock availability, financing options, and Canada-wide delivery.
Equip your fleet with the CAEL Integrated Tow & Recovery System — engineered for professional towing and demanding recovery operations.
