Description
GENERATOR
– PHASE : SINGLE
– FREQUENCY : 60HZ
– VOLTAGE : AC 120V/240V
– RATED POWER :6.2KW
– MAX POWER : 6.5KW
– RATED CURRENT : 25.8A
WELDING
-RATED DUTY CYCLE :35%
– OCV (v) : DC 65V+- 5%
– CURRENT RANGE (A) : DC 50-200A
-WELDING ROD : 1.6-4MM
– RATED CURRENT / VOLTAGE (A/V) : 160A /DC26.4V
ENGINE
-ENGINE MODEL : KOLHER CH440
-MAX POWER / SPEED (RPM) : 14HP /3600RPM
-DISPLACEMENT (CC) : GAS 429CC
– START NETHOD : RECOIL + ELECTRIC
– FUEL TANK : 18L
WEIGHT : 147 KG
