Technical Specifications – Forklift / Truck Specs

• Capacity: 1.5 t / 3,300 lb

• Load center (max): 500 mm / 19.6 in

• Lifting height: 4 m / 13 ft 1 in

• Reach distance: 550 mm / 21.6 in

• Weight (without battery): 2,340 kg / 5,158 lb

• Overall length (mast no reach):

  • Frame: 1,780 mm / 70 in

  • Machine: 2,350 mm / 92.5 in

• Overall length (mast reach): 2,860 mm / 112.5 in

• Overall width of frame: 1,035 mm / 40.7 in

• Overhead guard height: 2,180 mm / 85.8 in

• Mast lowered height: 2,200 mm / 86.6 in

• Forks:

  • Length: 1,070 mm / 42 in

  • Width: 100 mm / 3.9 in

  • Lowered height: 55 mm / 2 in

• Turning radius (min): 1,710 mm / 67 in

• Minimum intersecting aisle width: 2,610 mm / 102.7 in

Power & Drive

• Drive motor:

  • Type: AC motor

  • Rated output: 1.5 kW

• Hoist motor:

  • Type: DC motor

  • Rated output: 3 kW

• Battery: 24 V / 270 Ah

• Charger: 110 V charger
