– capacity: 2T (4400LBS0
– Load center:500mm/ 19.6in Maximum
– lifting height :4M (13FT1)
– Reach Distance:550mm/ 21.6 in
– Weight (without battery): 2340kg/ 5158 LBS
– Overall length of frame(mast no reach): 1780mm/ 70 in
– Overall length (mast no reach):2350mm/ 93.5 in
– Overall length (mast reach):2860mm/ 112.5 in
– Overall width of frame:1035mm/ 40.7 in
– Overhead guard height:2180mm/ 86 in
– Mast lowered height:2200mm/ 86.6 in
– Fork length:1070mm/ 42 in
– Fork width:100mm/ 3.9 in
– Fork lowered height:55mm/ 2.16 in
– Turning radius:1710mm/ 67in Min intersecting aisle width:2610mm/103 in
– Drive motor type :AC motor Rated output:1.5kw
– Hoist motor type: DC motor Rated output:3kw
– Battery :24V/270Ah
– 110V charger
