Description
Specification
– Brand : CAEL
– Machine working weight :(kg) 23000 kgs
– Bucket capacity(m3) : 0.5-1.28
-Boom length(mm) : 5700/ 224inch
-Stick length(mm) : 2900/114inch
-Overall width of transport(mm) : 2900/114inch
-Overall height of transport(mm) : 3030/119.29inch
-Full height of cab(mm) : 3000/118.11 inch
-Track length(mm) : 4440/ 174.80 inch
-Track full width(mm) : 2990/117.71 inch
-Track shoe width(mm) : 600/ 23.62inch
-Back end turning radius(mm) : 2750/ 108.26inch
-Minimum ground clearance(mm) : 480/ 18.89inch
Performance
– Swing speed(rpm) 12.4
– Walking speed(km/h) 3.1-4.5
– Bucket Digging Force (KN) : 136.2
Stick excavator(KN) 97
Scope of work
– Maximum excavation range (mm) : 9910/ 390.15inch
– Maximum excavation depth (mm) : 6445/ 253.74inch
– Maximum excavator height (mm) : 6045/ 237.99inch
– Maximum discharge height (mm) : 6810/ 268.11 inch
– Maximum vertical depth that can be excavated(mm) : 6045/ 237.99inch
Engine
– Engine model : Kubota
– Rated power(kw/rpm) : 110/1950
– Cooling method : water cooling
Body size
Total length of transport (mm) : 9510/ 374.40inch
2years warranty on motor
1year Warranty on all parts
Option Hydraulic Thumb: C$3000
Option Dozer Blade: C$3500
