Description
Model
Skip
Length : 1150mm/ 45 in
Width : 648mm/ 25.5 in
Height : 515mm/ 20 in
Capacity : 0.2 m3
Angle of dumping : 57° /47°
Angle from the ground : 10°
Engine
Model : BRIGGS & STRATTON
Fuel : gasoline
Rated power : 6.8Kw
rotating speed : 3000-/min
Cylinder : 1
Hvdraulic system
Motor : Big torque motor
Double pump : Gear pump
System pressure : 16MPa
System flow : 12ml/min
Hydraulic oil tank capacity : 19.4L
Body of machine
Operating weight : 600kg/ 1300 LBS
Load capacity : 500kg/ 1100 LBS
Fuel tank : 5.5L
Speed : 3.5km/h
