Description
Brand : CAEL
Rated loading capacity : 550kg/ 1212LBS
Platform height : 8m ( 26ft3) /10m (33ft ) /12m (39ft5)
Working height : 10/12/14meter (32.8/39.3/45.9FT)
Platform size : 2.41.17m/ 7.8 3.8FT
Overall dimension(stowed) : 2.7*1.5*1.82mm/ 0.10*0.05*0.07 in
Motor : 48v/4.0kw
Track : 1002400mm / 3.9 94.4 in
Basement : 8mm (0.3 in) thickness steel plate welding together
Cylinder : 80mm / 3.14 in
Platform : 3mm (0.11 in) anti-skid steel plate
Weight : 2700kgs / 5952LBS
